Brand New - Turbo Bits
Model: GT30
Bearing System: Journal
Flange: T3
Compressor: A/R .70
Turbine: A/R .48 - 78mm V-Band
HP Rating: 250-450hp
Engine size: 1500cc to 2500cc
Wastegate: Internal or External
Perfect size for TD42 Upgrade
This model comes with the billet compressor wheel. The A/R .48 exhaust housing it better suited to smaller displacement 4 and 6 cylinder engines as a single turbo up to 2500cc, as a twin turbo, up to 5000cc. It also features a removable rear housing to convert from internal to external gated. Feel free to contact us to discuss the best set up for your application we have lots of different options and sizes in stock.
COMPRESSOR DETAILS:
A/R 0.70
Anti Surge compressor cover
Air inlet 4.00" (We stock silicon joiners)
Air outlet: 2.50" (We stock silicon joiners)
Compressor Wheel Dimensions:
Inducer - 61.40mm
Exducer - 82.00mm
TURBINE DETAILS:
Turbine: A/R 0.48 - For faster spool up time
Exhaust outlet: 50mm/2" Outlet 78mm V-Band with internal gate or 5 Bolt for external
Entry Flange: T3
Turbine Wheel Dimensions:
Inducer - 65.00mm
Exducer - 49.00mm
TURBO DETAILS
Billet Compressor wheel, for faster spool up and stronger design
Anti Surge
Bearing type: Journal bearing
Cooling type: Water cooled - Can run oil cooled only but we recommend to run both.
Horsepower: 250-450hp
Recommended Boost: 10-20psi
Max Boost: 30psi
Wastegate: Internal & external (rear housing can be removed to run external gate)
ORDER TOGETHER AND SAVE
- Intercooler Kits
- Silicon Joiners
- Water fittings & water lines
- Oil fittings & Oil lines
- 38mm, 44mm or 60mm external V-Band wastegates
- Blow of valves
- Adjustable Fuel Pressure regulator
- V-Band flange & clamp set
- T3 Manifold adapters
- T3 Flanges
- Fuel Pumps
- Turbo Beanies
- Heat Wrap
- Oil coolers
- Boost & vacuum line
+ Much more - Just ask
