Description
Buy quality products from the knowledgeable turbo specialists with 15+ years in the business - Turbo Bits
Model: T04Z T70
Bearing System: Journal bearing
Flange: T4 Twinscroll
Compressor: A/R .70 - Anti Surge
Turbine: A/R .84 - 102mm (4") v-band
HP Rating: 400-650hp
Engine size: 2500cc to 6000cc
cooling: oil only
Item is 100% Brand New.
T4 Twinscroll for fast spooling
Perfect for RB25DET RB26DETT RB30DET 1JZGTE 2JZGTE VQ30DETT 13b 13btt rx7 rotory engines V6 & V8 Engines
Made of high quality.
This turbo is universal.
Max up to 30PSI,
Model: T04Z
Compressor:
A/7 0.70 (Anti surge)
air inlet:4"
air outlet:2.5"
inducer:66.6mm
exducer:84.00mm
Turbine:
A/R 0.84
Exhaust outlet:4" v-band
inducer:73.60mm
exducer:64.50mm
cooled type:oil cooled
Item exactly the same as picture shown.
Instruction is NOT included. Professional installation is highly recommended.
Can handle applications of up to 650HP
