Brand New - Turbo Bits
Model: T76
Bearing System: Journal
Flange: T4
Compressor: A/R .80 - Anti Surge
Turbine: A/R .84 - 101mm V-Band
HP Rating: 700-1000hp
Engine size: 5000cc to 10000cc
More Details:
This model comes with the anti surge and billet compressor wheel for efficient spool up. With the large T4 A/R .84 exhaust housing its better suited to larger displacement 6 and 8+ cylinder engines as a single turbo up to 10000cc, as a V8 twin turbo, 7000cc and above. Feel free to contact us to discuss the best set up for your application we have lots of different options and sizes in stock.
Model:
T76
COMPRESSOR DETAILS:
A/R 0.80
Anti surge compressor cover
Air inlet 4.00" (We have silicon joiners if required)
Air outlet: 2.50" (We have silicon joiners if required)
Compressor Wheel Dimensions:
Inducer - 76.74mm
Exducer - 102.30mm
TURBINE DETAILS:
Turbine: A/R 0.84
Exhaust outlet: V-Band 101mm
Entry Flange: T4
Turbine Wheel Dimensions:
Inducer - 73.80mm
Exducer - 64.50mm
TURBO DETAILS:
Brand New
Billet Compressor wheel, for faster spool up and stronger design
Anti Surge
Bearing type: Wet float journal bearing
Cooling type: Oil and water cooled - Can run oil cooled only but we recommend to run both.
Horsepower: 700hp-1000hp
Recommended Boost: 20psi
Max Boost: 30psi+
ORDER TOGETHER AND SAVE
- Intercooler Kits
- Silicon Joiners
- Water fittings and water lines
- Oil fittings and Oil lines
- 38mm, 44mm or 60mm external V-Band wastegates
- Blow of valves BOV
- Adjustable Fuel Pressure regulator
- V-Band flange and clamp set
- T3 Manifold adapters
- T3 Flanges
- Fuel Pumps
- Turbo Beanies
- Heat Wrap
- Oil coolers
- Boost and vacuum line
+ Much more - Just ask.
